RG 58 Coaxial Cable (50 Ω)
50 Ω braided coaxial cable with 19-strand tin-plated copper inner conductor and PVC jacket. General-purpose RF cable used up to 3 GHz for instrumentation, data and low-power RF interconnects.
Features & Characteristics
- ▪Tin-plated copper stranded inner conductor (19 × 0.18 mm)
- ▪Solid PE dielectric
- ▪16 × 7 × 0.12 mm braided outer conductor
- ▪RoHS PVC jacket
- ▪50 ± 2 Ω characteristic impedance
Applications
- ▪General purpose RF interconnect
- ▪Instrumentation and test setups
- ▪Low-power wireless equipment
Mechanical characteristics
- Inner conductor
- 19 × 0.18 mm ± 0.013
- Dielectric
- 2.95 ± 0.1 mm (solid PE)
- Outer conductor
- 16 × 7 / 0.12 mm braid, H = 20 ± 2 mm
- Jacket
- PVC, 4.85 ± 0.15 mm
- Bending radius (once)
- 25 mm
- Operating temperature
- -25 °C ~ +80 °C
- RoHS
- Yes
Electrical characteristics
- Capacitance
- 100 ± 5 pF/m
- Impedance
- 50 ± 2 Ω
- Velocity
- 66 %
- Max operating voltage
- 1.5 kV rms
- Max operating frequency
- 3000 MHz
- VSWR
- 1.25
Related products in RG / Aluminum Trunk Cables
View all →RG 59 Coaxial Cable (75 Ω)
75 Ω braided coaxial cable widely used in CATV, satellite receiving and HFC network transmission systems. Compact construction suited to short indoor and last-drop distribution runs.
RG 6 Coaxial Cable (75 Ω)
75 Ω braided coaxial cable with 4.57 mm foamed dielectric for CATV, satellite and broadband distribution runs. Offers lower attenuation than RG 59 at similar installation flexibility.
RG 11 Coaxial Cable (75 Ω)
75 Ω braided coaxial cable with 7.11 mm dielectric for medium-distance CATV and HFC trunk runs. Lower attenuation than RG 6 supports longer distribution feeders.
RG 8 Coaxial Cable (50 Ω)
50 Ω 10 mm braided coaxial cable with copper-clad-aluminum inner conductor for higher-power / lower-attenuation applications than RG 58. Bonded aluminum foil plus Al-Mg braid delivers strong shielding.
Aluminum Trunk Cable — LB412 / LB500 / LB565 / LB625 / LB750
