SFP

2.5G Transceivers

The 2.5G SFP variants target legacy 2.5G access, GPON auxiliary and mobile backhaul links: 15 km 1310 nm dual-LC and 15 km BIDI 1310 / 1550 nm single-fibre.

Download PDF Request a Quote

Features & Characteristics

▪SFP form factor
▪2.5 Gb/s NRZ
▪I/C temperature options
▪In-house hardware, coaxial and structural design
▪COB packaging and silicon-chip capability
▪Automated production platform with SI simulation
▪5 SMT + 5 transceiver assembly lines
▪Capacity: 150K modules/month at ≤ 25G, 70K/month at ≥ 100G
▪Full 1G–400G in-house test system (HT/LT, burn-in)

Applications

▪Legacy 2.5G aggregation
▪Mobile backhaul
▪GPON aux and OLT trunks
▪Data centre spine and leaf interconnect
▪Enterprise switch uplinks
▪Metro / access aggregation
▪5G fronthaul and midhaul
▪Carrier backbone transport

Available variants

The following 2 SKUs make up the 2.5g transceivers range. Contact us for spec sheets, sample availability and volume pricing on any variant.

Port	Distance	Wavelength	Temp	MPN	Power	TX min (dBm)	TX max (dBm)	Sensitivity (dBm)
Dual LC	15 km	1310 nm	I/C	ZMHP-131LONx	< 1.0 W	-5.0	0.0	-18.0
BIDI LC	15 km	1310 / 1550 nm	I/C	ZMHP-B2CLONx / ZMHP-BC2LONx	< 1.0 W	-5.0	0.0	-18.0

Temperature: C = commercial, I = industrial, E = extended, V = VCSEL. "x" in an MPN denotes I/C build option.
