Optical Fiber Cables
All Dry Cable
Fully dry-core optical cable using water-blocking tapes and yarns instead of filling gel. Speeds up cable preparation and splicing while maintaining full moisture protection.
Features & Characteristics
- ▪Gel-free cable core with dry water-blocking material
- ▪Separate fibers and ribbon fibers as optical unit; ribbon design eases splicing
- ▪Convenient for installation, reduces preparation and installation time
- ▪Speeds fiber access and clean-up
- ▪Reduces required tools
- ▪Metallic, non-metallic armored or unarmored
- ▪Duct, directly bury or aerial installation
Applications
- ▪Duct, direct-buried and aerial routes needing clean, fast splicing
Typical Specifications
- Duct type (OFC-24-FStD-S1)
- Ø 10.7 mm, 110 kg/km, 1000 N, 2000 N/10cm
- Buried type (OFC-24-FStDB-S1)
- Ø 13.5 mm, 155 kg/km, 2000 N, 3000 N/10cm
- Ribbon (OFC-288-R-FD-S1)
- 288 fibers, Ø 22.0 mm, 275 kg/km
