Micro Optical Fiber Cable
ZTT Micro Optical Fiber Cable (spec ZTT 17-78748-1-F) is designed for blowing installation into microducts. The range covers ultra-slim OFC-4/8/12 G.657A1 / G.657A2 microcables with an LSZH yellow sheath, and multi-loose-tube OFC-12/24/48/72/96/144 G.652D FMD cables with HDPE sheath, FRP central strength member, water-blocking yarn and ripcord. Compact sizes and low-friction outer surface enable air-blowing distances up to 2 km with a CBS air-blowing set. Manufactured in accordance with IEC 60793, IEC 60794-5, ITU-T G.650/G.652/G.657 and EIA/TIA 598.
Features & Characteristics
- ▪Air-blown fibers with outer surface promoting low friction
- ▪Light weight and small size, ideal for blowing installation
- ▪Saves duct resources in dense access networks
- ▪OFC-4/8/12 with G.657A1 or G.657A2 bend-insensitive fibers
- ▪OFC-12/24/48/72/96/144 with G.652D fibers in loose tubes
- ▪Unique extruding technology gives excellent bend endurance
- ▪Fiber excess-length control for stable optical and mechanical performance
- ▪Multiple water-blocking materials providing dual water-blocking function
- ▪FRP central strength member (multi-tube types)
- ▪LSZH yellow sheath (OFC-4/8/12) or HDPE black sheath (OFC-12+)
- ▪Compliant with IEC 60793 / 60794-5, ITU-T G.650/G.652/G.657, EIA/TIA 598
Applications
- ▪Air-blown installation in microducts
- ▪High-density urban FTTx and access networks
- ▪Metro backbone and distribution using microduct infrastructure
- ▪Duct-saving deployments over long distances (up to ~2 km per blow)
Typical Specifications
- Cable types
- OFC-4/8/12 G.657A1/G.657A2-MD-S3 · OFC-12/24/48/72/96/144 G.652D-FMD-S1
- Fiber types
- ITU-T G.652D, G.657A1, G.657A2
- Attenuation @1310 nm (G.652D, after cabling)
- ≤ 0.35 dB/km
- Attenuation @1550 nm (G.652D, after cabling)
- ≤ 0.22 dB/km
- Attenuation @1310 nm (G.657A1/A2, after cabling)
- ≤ 0.36 dB/km
- Attenuation @1550 nm (G.657A1/A2, after cabling)
- ≤ 0.22 dB/km
- PMD (G.652D)
- ≤ 0.2 ps/√km
- Cladding diameter
- 125 ± 1 μm
- Coating diameter
- 250 ± 15 μm
- Operation temperature
- −40 °C to +60 °C
- Installation temperature
- −30 °C to +60 °C
- Transport / storage temperature
- −40 °C to +70 °C
- Min. installation bend radius
- 20 × D
- Min. operation bend radius
- 15 × D
- Reference standards
- IEC 60793-1/2, IEC 60794-5, ITU-T G.650/G.652/G.657, EIA/TIA 598
- Air-blowing distance
- Up to 2 km (OFC-4/8/12) · ~1 km (higher fiber counts)
- Air pressure
- 15 bar
- Min. blowing speed
- 5 m/min
- OFC-4 G.657A1/A2 — OD × weight
- 1.2 ± 0.2 mm · 20.5 kg/km
- OFC-8 G.657A1/A2 — OD × weight
- 1.6 ± 0.2 mm · 31 kg/km
- OFC-12 G.657A1/A2 — OD × weight
- 1.8 ± 0.2 mm · 41 kg/km
- OFC-4/8/12 — max tensile / crush
- 15 N · 200 N/10 cm
- OFC-4/8/12 — sheath
- LSZH, yellow
- OFC-12/24/48/72 G.652D — OD × weight
- 5.7 ± 0.2 mm · 27 kg/km ± 10%
- OFC-12/24/48/72 — loose tubes / fillers
- 1/5 · 2/4 · 4/2 · 6/0 (12 fibers per tube)
- OFC-12/24/48/72 — max tensile / crush
- 700 N · 500 N/10 cm
- OFC-96 G.652D — OD
- max 6.5 mm (8 loose tubes × 12 fibers)
- OFC-144 G.652D — configuration
- 12 loose tubes × 12 fibers
- OFC-12+ — sheath / strength member
- HDPE black · FRP central member · water-blocking yarn · ripcord
